6ED1055-1MA00-0BA2
تومان375,000
توضیحات
6ED1055-1MA00-0BA2
6ED1055-1MA00-0BA2 Siemense LOGO! AM2 expansion module, PS/: 12/24V DC, 2 AI, 0-10 V or 0/4-20 mA for LOGO! 8
Installation type/mounting: on 35 mm DIN rail, 2 spacing units wide
Rated Voltage: 12-24V DC
Number of analog inputs: 2 AI
Input ranges
● Voltage: Yes ; 0-10 V
● Current: Yes ; 0-20 mA or 4-20 mA
● Resistance thermometer: No
Degree and class of protection: IP20
Standards, approvals, certificates: CE mark / CSA approval / UL approval / FM approval / developed in accordance with IEC 61131 / according to VDE 0631 / Marine approval
Ambient temperature Operation : 0 (LOGO! 8 ES03 and higher: -20 °C ) … 55 °C (32 … 131 °F)
Dimension : 35.5x90x58 (WxHxD)
کارت اکسپنشن آنالوگ
تغذیه ورودی | 12-24V DC |
فرکانس کاری | 47-63HZ |
تعداد ورودی و خروجی آنالوگ | 2AI |
نوع ورودی آنالوگ | ولتاژ / جریان |
حفاظت | IP20 |
ابعاد کارت اکسپنشن (میلیمتر) W x H x D | 58*90*35.5 |
